Granulation Machine Pharmaceutical Rotary Granulator Granule Making Machine

APM-USA

$10,400.00
SKU: P3186S

Product Description

This machine can make granules from wet powder materials or break down the dry lumpish material, which is widely used by the industries of pharmacy, chemical, and food stuff etc.

Working method: By driving of mechanism, the cylinder is swing to and fro to force the target materials squeezed from sieve to make out granules or to smash it as granules.

Features:
1.This Oscillating granulating machine makes use of the rolling motion of rotating barrel, granulates the wet powder materials into granule by sieve, it also can be used to crush agglomerate materials into small granules directly.


2. In chemical medicine field, it can be used for granulating the mixed powder into granule, and compressed into tablet after being dried. It also can be used for granulating the coagulated material that is formed during storage or during chemical processing, In food industry, it can be used to deal with the candy and sugar mixture as well as barley milk products. In other industries, it can be used to granulate such as porcelain and plastic mixtures into forming granules.


3. It is not suitable for solid, fluid medium, paste or pulverizing.


4.Its mesh number of sieve should be prepared by users, according to the size of granule.

Technical Parameters
Model
YK-90
Production capacity
50-100KG/h
Hob diameter
90mm
Hob rotating speed
±50rpm
Hopper section size(L*W)
300*280mm
Motor power
550W
Machine net weight
100KG
Dimension
670*440*790mm
Warranty
1 year

All datas are used for reference only. According to the condition of material, there will be no further notification if any modification.
