Wldh- Horizontal Ribbon Mixer

APM-USA

$4,000.00
SKU: P5430S

Application

WLDH-Horizontal Ribbon Mixer is a pioneer product researched and a new high-efficiency mixer. It is widely used in the solid-solid (powder material) and solid-liquid (powder material & fluidity material) mixing in the filed of chemical industry, pharmacy, foodstuff industry, etc.

Working principle:

WLDH series mixer is mainly comprised of mixing barrel, spiral ribbon and driven-parts. The spiral ribbon is made of two layers. That is, the inner ribbon makes the material move outwards, while the external ribbon makes the material move inwards which forms a good circulation of material. Ribbon moves so circumferentially that the mixer could achieve fine mixing efficiency in a very short time.

Technical Parameters:



Model

Barrel Volume(L)

Loading Volume?L?

Mixing Time?min?

Stir Motor?kw?

Weight?kg?

WLDH-100

100

30-60

8-20

1.5-4

320

WLDH-300

300

100-180

8-20

3-5.5

510

WLDH-500

500

200-300

8-20

4-11

920

WLDH-1000

1000

400-600

8-20

7.5-15

1450

WLDH-1500

1500

600-900

8-20

11-18.5

1950

WLDH-2000

2000

800-1200

8-20

18.5-30

3160

WLDH-3000

3000

1200-1800

8-20

18.5-30

3300

WLDH-4000

4000

1600-2400

8-20

22-37

3620

WLDH-6000

6000

2400-3600

8-20

37-55

5400

WLDH-8000

8000

3200-4800

8-20

37-55

6880

WLDH-10000

10000

4000-6000

8-20

45-75

7900
